- 5G
- Android 11
- Octa-core 2.4GHz
- 6.2”screen
- 6GB RAM+128GB ROM
- Wi-Fi 6
- IP68
- High-performance scanner
Wi-fi 6, 5G
High performance barcode scanning
WiFi 6 brings fast experience and makes work more efficient
Dual card and dual standby, 5G full Netcom, supporting 5G frequency bands
Equipped with professional code scanning module, can quickly and accurately analyze various barcodes
Strong performance and smooth operation
8-core 2.4GHz CPU, equipped with android11 operating system
6GB RAM + 128GB ROM, large memory, more smooth multitasking
6.2 inch full screen, hold with one hand
6.2-inch full view, high sensitivity touch screen
Support multi touch, glove touch, operation with water and passive pen signature, making operation more convenient
Front speaker, no fear of noisy environment, clear and visible sound
IP68 advanced protection level
IP68 dust-proof and waterproof, facing severe challenges
1.5m drop resistance, drop resistance and wear resistance, easy to cope with bad weather such as rain, snow and fog
HD dual camera
Front: 8 MP, rear: 13 MP
Flexible switching, accurate display
5300mAh large battery and 15W quick charge
5300mAh large battery is removable and durable to provide endurant operation time for typical 8-12 hours.
Support 15W quick charge
-
Healthcare
-
Logistics
-
Manufacturing
-
Warehouse
-
Ticketing
-
Retail
-
Physical parameters Size 135*60.5*21.3mm Display 6.2-inch IPS screen, resolution: 1520 * 720 Touch screen Capacitive touch, support wet hand and glove operation Backlight LED backlight Battery Polymer lithium battery, capacity: 5300mah 3.8V, working time: more than 8 hours, standby: 280 hours Card slot 2 SIM card slots, 1 micro SD card slot (maximum 256GB) Communication interface Type-C, supporting OTG Network connections 5G/4G/3G/2G, Wi-Fi 6, GPRS, Bluetooth, GPS, BDS, GLONASS Key Power key; Two scan keys; Volume + - key Power adapter Input: 100-240V; Output: 5v3a / 7v21A/ 9V1. 5A /12V1. 25A telecommunications WWAN 5G: Mobile
GSM: 2 / 3 / 5 / 8
WCDMA: 1 / 2 / 5 / 8
TDS: 34 / 39 (compatible)
TDD: 34 / 38 / 39 / 40 / 41
FDD: 1 / 2 / 3 / 5 / 7 / 8 / 20 / 26 / 28ab
CDMA: bc0
5G: N1 / N3 / N8 / N38 / N41 / N77 / N78 / N79 / N28abWIFI WiFi frequency: 2.4GHz & 5GHz WiFi protocol: 802.11a/b/g/n/ac/ax/k/r/v/w Positioning system Support dual band GPS / GALILEO / GLONASS / BDS Bluetooth Bluetooth 5.1 -
Internet of things function NFC Operating band: 13.56MHz supported protocols: mifareclassic (MF1) nDef, nfcv (15693), ultrahigh (mf0), isodep (quasi CPU MF3), isodep (CPU) reading distance: 0-5cm (depending on the type of video card) RFID NO Security PSAM NO Sensor Optical distance sensor, gravity sensor, acceleration sensor, geomagnetic sensor, pedometer sensor performance parameter CPU Octa core 2.4GHz Operating system Android 11 Memory 6GB RAM/128GB ROM data acquisition Barcode scanning module Support barcode and QR code scanning Support one-dimensional barcode type UPC / EAN, bookland EAN, UCC coupon code, ISSN EAN, code 128, gs1-128, ISBT 128, code 39, trioptic Code 39, code 32, code 93, code 11, interleaved 2 of 5, discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Korean 3 of 5, matrix 2 of 5, inverse 1D, GS1 DataBar, composite codes, etc Supports 2D barcode types PDF417, MicroPDF417, data matrix, data matrix inverse, MaxiCode, QR code, microqr, QR inverse, Aztec, Aztec inverse, postal codes: US Postnet, US planet, UK postal, Australian postal, Japan postal, Netherlands KIX code, USPS 4CB / one / intelligent mail, UPS FICS pstal, etc Camera Front camera: 8 million pixels front camera: 13 million pixels auto focus rear camera flash; Support flashlight mode
-
