  • 5G
  • Android 11
  • Octa-core 2.4GHz
  • 6.2”screen
  • 6GB RAM+128GB ROM
  • Wi-Fi 6
  • IP68
  • High-performance scanner

Wi-fi 6, 5G
High performance barcode scanning

WiFi 6 brings fast experience and makes work more efficient

Dual card and dual standby, 5G full Netcom, supporting 5G frequency bands

Equipped with professional code scanning module, can quickly and accurately analyze various barcodes

Strong performance and smooth operation

8-core 2.4GHz CPU, equipped with android11 operating system

6GB RAM + 128GB ROM, large memory, more smooth multitasking

6.2 inch full screen, hold with one hand

6.2-inch full view, high sensitivity touch screen

Support multi touch, glove touch, operation with water and passive pen signature, making operation more convenient

Front speaker, no fear of noisy environment, clear and visible sound

IP68 advanced protection level

IP68 dust-proof and waterproof, facing severe challenges

1.5m drop resistance, drop resistance and wear resistance, easy to cope with bad weather such as rain, snow and fog

Highly integrated design for widely industry applications
Barcode/RFID/PSAM/NFC/Camera

HD dual camera

Front: 8 MP, rear: 13 MP

Flexible switching, accurate display

5300mAh large battery and 15W quick charge

5300mAh large battery is removable and durable to provide endurant operation time for typical 8-12 hours.

Support 15W quick charge

Applications
V5 series mobile computers are widely deployed in logistics, transport, healthcare, retail, manufacturing, warehouse management, attendance management etc.
  • Healthcare Healthcare
  • Logistics Logistics
  • Manufacturing Manufacturing
  • Warehouse Warehouse
  • Ticketing Ticketing
  • Retail Retail
Specifications
  • Physical parameters
    Size 135*60.5*21.3mm
    Display 6.2-inch IPS screen, resolution: 1520 * 720
    Touch screen Capacitive touch, support wet hand and glove operation
    Backlight LED backlight
    Battery Polymer lithium battery, capacity: 5300mah 3.8V, working time: more than 8 hours, standby: 280 hours
    Card slot 2 SIM card slots, 1 micro SD card slot (maximum 256GB)
    Communication interface Type-C, supporting OTG
    Network connections 5G/4G/3G/2G, Wi-Fi 6, GPRS, Bluetooth, GPS, BDS, GLONASS
    Key Power key; Two scan keys; Volume + - key
    Power adapter Input: 100-240V; Output: 5v3a / 7v21A/ 9V1. 5A /12V1. 25A
    telecommunications
    WWAN 5G: Mobile
    GSM: 2 / 3 / 5 / 8
    WCDMA: 1 / 2 / 5 / 8
    TDS: 34 / 39 (compatible)
    TDD: 34 / 38 / 39 / 40 / 41
    FDD: 1 / 2 / 3 / 5 / 7 / 8 / 20 / 26 / 28ab
    CDMA: bc0
    5G: N1 / N3 / N8 / N38 / N41 / N77 / N78 / N79 / N28ab
    WIFI WiFi frequency: 2.4GHz & 5GHz WiFi protocol: 802.11a/b/g/n/ac/ax/k/r/v/w
    Positioning system Support dual band GPS / GALILEO / GLONASS / BDS
    Bluetooth Bluetooth 5.1
  • Internet of things function
    NFC Operating band: 13.56MHz supported protocols: mifareclassic (MF1) nDef, nfcv (15693), ultrahigh (mf0), isodep (quasi CPU MF3), isodep (CPU) reading distance: 0-5cm (depending on the type of video card)
    RFID NO
    Security PSAM NO
    Sensor Optical distance sensor, gravity sensor, acceleration sensor, geomagnetic sensor, pedometer sensor
    performance parameter
    CPU Octa core 2.4GHz
    Operating system Android 11
    Memory 6GB RAM/128GB ROM
    data acquisition
    Barcode scanning module Support barcode and QR code scanning
    Support one-dimensional barcode type UPC / EAN, bookland EAN, UCC coupon code, ISSN EAN, code 128, gs1-128, ISBT 128, code 39, trioptic Code 39, code 32, code 93, code 11, interleaved 2 of 5, discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Korean 3 of 5, matrix 2 of 5, inverse 1D, GS1 DataBar, composite codes, etc
    Supports 2D barcode types PDF417, MicroPDF417, data matrix, data matrix inverse, MaxiCode, QR code, microqr, QR inverse, Aztec, Aztec inverse, postal codes: US Postnet, US planet, UK postal, Australian postal, Japan postal, Netherlands KIX code, USPS 4CB / one / intelligent mail, UPS FICS pstal, etc
    Camera Front camera: 8 million pixels front camera: 13 million pixels auto focus rear camera flash; Support flashlight mode
